Amarr 2747 Polyurethane Insulated Commercial Door
High R-Value Doors to Meet All Your Needs
Overview
Amarr 2741 energy-efficient Polyurethane Insulated is designed to maximize your budget’s value. The sections are insulated with foamed-in-place polyurethane, which creates a strong monolithic panel. It comes with a 10-year warranty and has a max std. width of 18′ 2″ and a max std. height of 14′ 1″. The door is 1-3/8″ (3.5cm) thick.
- Rapid Install Artificial Lift: Designed specifically for commercial warehouse and dock doors and saves approximately 20 minutes of installation time per door due to fewer jamb attachments and a pre-assembled, one-piece track. Available for door sizes up to 9’4″x10′.
- Track: All Amarr doors are available with both 2″ or 3″ track in Standard Lift, High Lift, Vertical Lift, Rapid Install Vertical Lift, Low Headroom, and Follow the Roof Pitch
- Springs: Torsion springs are oil tempered, helical wound, and custom computed for each door for a minimum 10,000 cycle life. Optional springs are available for up to 100,000 cycles.
- Hardware: Galvanized steel hinges and track brackets. All rollers have a minimum of 10-ball bearings.
- Maximum Door Size: 24′ 2″ W x 26′ 1″ H
- Steel Thickness: 27 ga
Available with Rapid Install
The Rapid Install system for Amarr’s Vertical Lift doors is designed specifically for commercial sectional doors, saving approximately 20 minutes of installation time per door.
Simplified Track & Hardware
- Heavy .063 gauge 1-piece 2″ and 3″ vertical track
- Preassembled end bearing plate
- Self-lubricating nylon rollers
- Widebody hinges
- Optional keyed hollow shaft
Reduced Installation Time
- Engineered for one-man installation
- Fewer trips up the wall
- Fewer components to assemble
- 10 fewer wall attachments
True White
Sandstone
Commercial Gray
Brown
26″ x 13″ insulated
24″ x 8″ insulated
| R-Value | 15.0 |
| Steel Thickness | 27 ga |
| Panel Design | Wide Groove |
| Steel Embossment | Stucco |
| Construction Layers | Three |
| Max Std Width | 24’2″ |
| Max Std Height | 26’1″ |
| Door Thickness | 1-5/8″ |
| U-Value | 0.066 |
Steel + Insulation + Steel
- Steel Exterior
- Polyurethane Insulation
- Steel Interior
- Interior Hinge Reinforcement
- Bottom Weather Seal
Construction:
- R-Value*: 15.1
- 1-5/8″ thick
- 27-gauge steel front
- 29-gauge steel interior panel
- 20-gauge continuous strip hinge reinforcement
- Available with Rapid Install
- Shiplap profile compatible with doors from other manufacturers
- Section weights are comparable to competitor products so no spring changes required
- 10-Year Limited Warranty
Brochures
Energy Efficient Polyurethane Insulated Brochure – Download pdf
Warranty
Commercial Sectional Warranty – Download pdf
